    Notes On Geography-Earthquake-For W.B.C.S Examination.

    নোট অন জিওগ্রাফি – ভূমিকম্প – WBCS পরীক্ষার জন্য।

    Earthquake

    • All natural earthquakes occur in the lithosphere.
    • Seismic waves studies offer a full picture of the layered interior.
    • An earthquake is, simply put, shaking of the earth’s crust.
    • It is caused due to the energy release, which triggers waves that travel in all directions.
    • The emanation of energy occurs along a fault.
    • A fault is a sharp break in the crustal rocks.
    • Rocks along a fault generally move in opposing directions.

    Types of Earthquakes

    • Tectonic earthquakes: These are produced due to sliding of rocks along a fault plane.
    • Volcanic earthquake: These are confined to areas of active volcanoes.
    • Collapse earthquake: The roofs of underground mines collapse causing minor tremors in the areas of intense mining activity.
    • Explosion earthquakes: These occur due to the explosion of chemical or nuclear devices.
    • Reservoir induced earthquakes: These occur in the areas of large reservoirs.

    Causes of Earthquakes

    • It is caused due to the discharge of energy from faults and cracks in the crust of the earth.
    • A fault in the crust of Earth is essentially a sharp break in crustal rocks.
    • This energy release produces waves which travel in all directions.
    • The point where energy is released is called the focus or hypocentre. It is generally located at the depth of 60 km.
    • This causes a release of energy, and the energy waves travel in all directions.
    • The point where the energy is released is called the focus of an earthquake or hypocentre.
    • The point on the surface of the earth which is vertically above the focus is called epicentre. It is the first place to experience the waves.
    Body Waves
    • Earthquake waves are of two types — body waves and surface waves.

    P- Waves

    • P-waves are also known as the Primary waves. They are the first waves to arrive at the surface.
    • The characteristics of P-waves are like sound waves. They travel through all three mediums- solid, liquid and gas.
    • These waves have a tendency to vibrate parallel to the direction of wave propagation. This causes density differences in the material through which they travel.
    • These waves are responsible for elongating and squeezing of material.

    S- Waves

    • S- Waves arrive after some time after the happening of Earthquake and they are called secondary waves.
    • A significant characteristic of these S-waves is that they travel only through a solid medium.
    • The direction of vibration of these S – wave is perpendicular to the direction of wave propagation, thereby creating crests and troughs in the material of their transmission.

    Shadow Zone

    • The shadow zone is the zone of the earth from angular distances of 104 to 140 degrees from a given earthquake that does not receive any direct P waves.
    • The shadow zone results from P waves being refracted by the liquid core and S waves being stopped completely by the liquid core.
    • A zone between 105° and 145° from the epicentre was recognised as the shadow zone for both the waves types.
    • The entire zone beyond 105° does not receive S-waves.
    • The shadow zone of S-wave is larger than that of the P-waves.
    • The shadow zone of P-waves appears as a band around the earth between 105° and 145° away from the epicentre.



    Effects of earthquake

    The following are the immediate hazardous effects of Earthquake:

    • Shaking of ground
    • Disparity in ground settlement
    • Natural disasters like Tsunami, land slide, mud slides and avalanches
    • Soil liquefaction
    • Ground lurching and displacement
    • Floods and fires
    • Infrastructure collapse.



    Measurement

    All earthquakes are different in their intensity and magnitude. The instrument for measurement of the vibrations is known as Seismograph.

    Magnitude scale

    • Richter scale is used to measure the Magnitude of earthquake
    • The energy released during a quake is expressed in absolute numbers of 0-10.

    Intensity scale

    • Mercalli scale is used to measure the intensity of earthquake
    • It measures the visible damage caused due of the quake.
    • It is expressed in the range of 1-12.
