W.B.C.S. Examination Notes On – Noise-to-Signal Ratio – Electrical Engineering Notes.

In analog and digital communications, signal-to-noise ratio, often written S/N or SNR, is a measure of signal strength relative to background noise. The ratio is usually measured in decibels (dB) using a signal-to-noise ratio formula.Continue Reading W.B.C.S. Examination Notes On – Noise-to-Signal Ratio – Electrical Engineering Notes.

If the incoming signal strength in microvolts is V_s, and the noise level, also in microvolts, is V_n, then the signal-to-noise ratio, S/N, in decibels is given by the formula: S/N = 20 log₁₀(V_s/V_n)

If V_s = V_n, then S/N = 0. In this situation, the signal borders on unreadable, because the noise level severely competes with it. In digital communications, this will probably cause a reduction in data speed because of frequent errors that require the source (transmitting) computer or terminal to resend some packets of data.

Ideally, V_s is greater than V_n, so a high signal-to-noise ratio is positive. As an example, suppose that V_s = 10.0 microvolts and V_n = 1.00 microvolt. Then:

S/N = 20 log₁₀(10.0) = 20.0 dB

This results in the signal being clearly readable. If the signal is much weaker but still above the noise — say, 1.30 microvolts — then:

S/N = 20 log₁₀(1.30) = 2.28 dB

This is a marginal situation. There might be some reduction in data speed under these conditions.

If V_s is less than V_n, then S/N is negative, representing a low signal-to-noise ratio. In this type of situation, reliable communication is generally not possible unless steps are taken to increase the signal level and/or decrease the noise level at the destination (receiving) computer or terminal.

Communications engineers always strive to maximize the S/N ratio. Traditionally, this has been done by using the narrowest possible receiving-system bandwidth consistent with the data speed desired. However, there are other methods. In some cases, spread spectrum techniques can improve system performance.

The S/N ratio can be increased by providing the source with a higher level of signal output power if necessary. In some high-level systems such as radio telescopes, internal noise is minimized by lowering the temperature of the receiving circuitry to near absolute zero (-273 degrees Celsius or -459 degrees Fahrenheit). In wireless systems, it is always important to optimize the performance of the transmitting and receiving antennas.
